Maxim/NewEngland 9mm Unity 30m 2xDry Rope

Unity 9mm 2xDry
Unity 9mm 2xDry
Maxim/New England

Used as a half rope, the Unity is designed to be alternately clipped to protection and constructed to reduce drag and increase fall protection over sharp edges. The Unity provides outstanding performance on routes with multiple traverses. Unity is also light enough and tough enough to be used as a glacier rope on the world's toughest mountains. Unity is available in 8mm iEndura Dry and 2X Dry or 9mm in 2X Dry. Select models feature our exclusive TPT sheath.

Rope Length Range:
49m & under
No votes yet

Technical Specifications

Weight (in grams per meter) 50.6g/m
Weight (in pounds) 3.346 lbs
Diameter (in millimeters) 9.0 mm
Length (in meters) 30
The Rated Rope Types Half (Double)
Type of Middle Mark None
UIAA Falls (Single / Half / Twin) - / 8 / -
Dynamic Elongation (Single / Half / Twin) 0.0% / 40 % / 0 %
Static Elongation (Single / Half / Twin) 0% / 10 % / 0 %
Impact Force (Single / Half / Twin) 0.00 kN / 8.00 kN / 0.00 kN
Dry Treatment Sheath & Core
Sheath Proportion
Sheath Slippage
End Marker None
RFID Optional None

Similar Ropes

9mm Unity 50m 2xDry  -  $214.00
Unity 9mm 2xDry
9mm Unity 60m 2xDry  -  $244.00
Unity 9mm 2xDry
9mm Unity 70m 2xDry  -  $278.00
Unity 9mm 2xDry
9mm Unity 200m 2xDry  -  $767.00
Unity 9mm 2xDry


Officially, Maxim lists the Dynamic Elongation as <=40 and the Static Elongation as <=10.
